75 CFM Refrigerated Air Dryer for Moisture Removal in Spray Painting & CNC Machines

The 75 CFM Refrigerated Air Dryer is the perfect solution for moisture control in spray painting, air compressors, and CNC machines. This reliable air dryer removes harmful moisture from compressed air, reducing equipment wear and improving finish quality. With a 75 CFM airflow, it provides the dry air needed to keep your operations running smoothly and your equipment in top condition.

Design Characteristics

• Unique three-in-one plate type heat exchanger design, compact structure, high heat transfer efficiency. Compare to traditional shell tube heat exchanger, unit heat transfer area enlarges 5 to 10 times.
• High strength aluminum alloy and stainless steel design which is small and light.
• Imported refrigerated valve, compressor is Panasonic.
• Economic auto drain.
• Sensitive and reliable instrument control components

Specification:

• Working Pressure: 0.7-1.3MPa
• Rated Capacity: 2.1 M3/min
• Refrigerant: R134a
• Max Inlet Temperature: 50°C
• Maximum Ambient Temperature: 35°C
• Pressure Dew Point: 3~10°C
• Voltage: 230V / 1Ph / 50Hz
• Dimension: 550*370*704
• Net weight: 75KG
