40 CFM Air Dryer for Moisture-Free Spray Painting CNC & Air Compressors Reliable Moisture Removal

Protect Your Equipment with Reliable Moisture Control

Ensure your spray painting, CNC machinery, and air compressors operate smoothly with our 40 CFM Air Dryer. By removing moisture from your compressed air system, this dryer protects your tools and machinery from rust, corrosion, and malfunctions.

Design Characteristics

• Unique three-in-one plate type heat exchanger design, compact structure, high heat transfer efficiency. Compare to traditional shell tube heat exchanger, unit heat transfer area enlarges 5 to 10 times.
• High strength aluminum alloy and stainless steel design which is small and light.
• Imported refrigerated valve, compressor is Panasonic.
• Economic auto drain.
• Sensitive and reliable instrument control components

Specification:

• Working Pressure: 0.7-1.3MPa
• Rated Capacity: 1.1 M3/min
• Refrigerant: R134a
• Max Inlet Temperature: 50°C
• Maximum Ambient Temperature: 35°C
  Pressure Dew Point: 3~10°C
• Voltage: 230V / 1Ph / 50Hz
• Dimension: 352*430*445
• Net weight: 32KG
