11CFM 75L Tank Piston Air Compressor 2HP/1.5KW 240V 115PSI Single 8BAR for Heavy Duty

Description

This 11CFM piston air compressor with a 75L tank offers 2HP/1.5KW power and operates at 115PSI for reliable, high-efficiency performance. Designed for heavy-duty use, it’s perfect for powering air tools like nail guns, spray guns, and pneumatic wrenches.

The 240V motor ensures consistent airflow, making it ideal for vehicle repairs, tire inflation, and workshop projects. With a durable design, this compressor delivers steady air pressure, minimizing downtime and boosting productivity.

• Rated to AS4637
• Heavy duty “close grain” cast iron construction.
• Guarding meets Occupational Health and Safety Standards
• Capacitor start/Capacitor run electric motor
• Full range of spare parts
• Designed for continuous duty
• Large canister intake filters with replaceable filter elements
• Deep fined cast iron cylinders. cooler tubes ensuring superior heat dissipation for higher operating efficiency.
• Aero-dynamically designed fan with large blades for higher air flow
• Two rubber tyred wheels for easy handling and manoeuvrability
• High-efficiency reed valves for maximum performance.

Specification

• Pump: G2070
• Cylinder: 70X2
• FAD: 314L/MIN FAD
• Air receiver, conforming to Australian standards – AS1210
• Pump drive: Double V section A type belt wheel
• Pump RPM: 2850RPM
• Motor Power: 1.5 KW/2HP
• Motor RPM: 2850RPM
• Pressure: 115 PSI / 8Bars
• Tank size (L):75
• Includes filter/regulator kit
• Condor MDR1/11 EV1S Pressure Switch installed
• Packaging dimensions: 1125 X 425 X 920
• Gross weight: 125 KG
• Recommended oil; 15W40W
• Power Source: Corded Electric
• Maximum Working Pressure: 8 BARS
• Item Length: 1125
• Item Height: 920
• Item Weight: 110KG
• Item Width:425
• Flow Rate: 314L/min
• Lubrication Type: Oil-Lubricated
• Tank Capacity:    75 L
• Material: Cast Iron
• Voltage: 240 V
• Set Includes: Condor Pressure Switch, Filter Regulator, Manual Drain Valve, Oil Sight Glass, Pressure Gauge, Pressure Safety Valve Tank
